Parámetro |
Descripción |
Modelo |
FusionServer 1288H V5 |
Factor de forma |
1tu, 2-servidor en rack |
Processors |
1 o 2 1st Generation Intel® Xeon® Scalable processors (3100/4100/5100/6100/8100 serie), hasta 205 W |
|
1 o 2 2nd Generation Intel® Xeon® Scalable processors (3200/4200/5200/6200/8200 serie), hasta 205 W |
Memoria |
24 Ranuras DIMM DDR4, 2933 MT/s; hasta 12 Intel® Optane™ PMem modules (100 serie), 2666 MT/s |
Almacenamiento local |
Supports hot-plug hard drives and the following configuration options: |
|
10 x 2.5-inch hard drives (6–8 NVMe SSDs and 2–4 SAS/SATA drives, con un número total de 10 o menos) |
|
10 x 2.5-inch SAS/SATA/SSDs (2–4 NVMe SSDs and 6–8 SAS/SATA HDDs, con un número total de 10 o menos) |
|
10 x 2.5-inch SAS/SATA/SSDs |
|
8 x 2.5-inch SAS/SATA hard drives |
|
4 x 3.5-inch SAS/SATA hard drives |
|
Flash storage: |
|
2 M.2 SSDs |
RAID Support |
REDADA 0, 1, 10, 5, 50, 6, o 60 |
|
Configured with a supercapacitor for power-off protection for the cache (opcional) |
|
Migración de nivel RAID, conducir itinerante, autodiagnóstico, and web-based remote configuration |
Network Ports |
LOM: 2 x 10GE + 2 x GE ports |
|
Flexible NIC: 2 x GE, 4 x GE, 2 x 10GE, 2 x 25GE, o 1/2 x 56G FDR IB ports |
Expansión PCIe |
Hasta 5 PCIe 3.0 tragamonedas, incluido 1 for a RAID controller card and 1 for a flexible NIC |
Fan Modules |
7 hot-swappable fan modules with optional N+1 redundancy |
Fuente de alimentación |
2 hot-swappable PSUs with support for 1+1 redundancy and the following configuration options: |
|
550W AC Platinum PSUs |
|
900W AC Platinum/Titanium PSUs |
|
1,500W AC Platinum PSUs |
|
1,500W 380V HVDC PSUs |
|
1,200W -48V to -60V DC PSUs |
Gestión |
BMC integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automated O&METRO, y refuerzo de la seguridad del hardware |
|
BMC supports standard interfaces such as Redfish, SNMP, y IPMI 2.0; provides a remote management interface based on HTML5/VNC KVM; supports CD-free deployment and the Agentless feature, simplifying management |
|
(Optional) Configured with the FusionDirector management software to provide advanced management features such as stateless computing, batch OS deployment, and automated firmware upgrade, enabling smart and automatic entire-lifecycle management |
Temperatura de funcionamiento |
5ºC to 45ºC (41ºF to 113ºF), and ASHRAE A3 and A4 compliant |
Certifications |
CE, UL, FCC, CCC, y RoHS |
Installation Kit |
Rieles guía en forma de L, rieles de guía ajustables, y rieles de sujeción |
Dimensiones (Alto x ancho x profundidad) |
Chassis with 3.5-inch hard drives: 43 mmx 447 mmx 748 milímetro (3.39 en. X 17.60 en. X 29.45 en.) |
|
Chassis with 2.5-inch hard drives: 43 mmx 447 mmx 708 milímetro (3.39 en. X 17.60 en. X 27.87 en.) |
