Server rack FusionServer 5288 V7

Fattore di forma	4Server rack U
Processore	1 O 2 x 4th/5th Gen Intel® Xeon®Scalable processors, con fino a 385 W TDP per processor
chipset	Emmitsburg PCH
Memoria	32 x DDR5 DIMMs, con fino a 5600 MT/s speed
Local Storage	Hot-swappable drive configurations:
	• 4 x 2.5ʺ SAS/SATA drives/SSDs
	• 24 A 44 x 3.5ʺ SAS/SATA drives
	• 4 x NVMe SSDs
	• E1.S or E3.S SSDs*
	Memoria flash:
	• 2 x SSD M.2
RAID	RAID 0, 1, 10, 1E, 5, 50, 6, O 60; optional supercapacitor for cache data power failure protection, Migrazione a livello RAID, guidare in roaming, autodiagnosi, and remote web-based configuration
Rete	Expansion capability for multiple types of networks
	OCP 3.0 NICs are supported. I due slot per schede FlexIO supportano due OCP 3.0 NICs, che può essere configurato come richiesto. Hot swap and PCIe 5.0 sono supportati
Espansione PCIe	Fino a 10 x PCIe slots, Compreso 2 x FlexIO slots dedicated for OCP 3.0 NICs and 10 x PCIe expansion slots. PCIe 5.0 is supported
GPU Card	10 x single-width GPU cards
Modulo ventola	6 O 8 x hot-swappable counter-rotating fans in N+1 redundancy
Power Supply	900 W/1200 W/1500 W/2000 W/3000 W Platinum/Titanium hot-swappable PSUs in 1+1 redundancy
Gestione	The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, e rafforzamento della sicurezza hardware
	• The iBMC supports standard interfaces such as Redfish, SNMP, e IPMI 2.0, fornisce un'interfaccia di gestione remota basata su HTML5/VNC KVM, and supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management
	• It is optional to configure the FusionDirector management software that provides advanced management features such as five intelligent technologies and realizes intelligent, automated, visualized, and refined management throughout the lifecycle
OS	FusionOS, Server Microsoft Windows, SUSELinux Enterprise Server, VMware ESXi, RedHat EnterpriseLinux, CentOS, Oracle, Ubuntu, Debian, and openEuler . For more, click here
Sicurezza	Password di accensione, administrator password, Trusted Platform Module (TPM) 2.0, security bezel, secure boot, and chassis intrusion detection

Temperatura operativa	5ºC to 35ºC (41ºF to 95ºF), Class A1/A2
Certification	CE, UL, CCC, FCC, VCCI, e RoHS
Suite di installazione	Guide di scorrimento a L, guide di scorrimento regolabili, e tenendo le rotaie
Dimensioni (A x L x P)	Chassis with 3.5ʺ drives: 175 mm × 447 mm × 798 mm (6.89 In. X 17.60 In. X 31.42 In.)
