Specifiche tecniche
NAS Scale-out: 12 High Availability pairs
| Maximum SSDs | 576 NVMe |
|---|---|
| Maximum Raw Capacity: All Flash | 8.84PB / 7.85PiB |
| Effective Capacity (based on 3:1) | 26.43PB / 23.47PiB |
| Maximum Memory | 1536GB |
SAN Scale-out: 6 High Availability pairs
| Maximum SSDs | 288 NVMe |
|---|---|
| Maximum Raw Capacity | 4.42PB / 3.92PiB |
| Effective Capacity | 17PB / 15.1PiB |
| Maximum Memory | 768GB |
| Cluster Interconnect | 4 x 25GbE |
Per High Availability Array Specifications: Active-Active Controller
| Maximum SSDs | 48 NVMe |
|---|---|
| Maximum Raw Capacity: All-Flash | 737.28tubercolosi / 670.29TiB |
| Effective Capacity | 2.11PB / 1.87PiB |
| Controller Form Factor | 2U chassis with two High Availability controllers and 24 NVMe SSD slots |
| Memoria | 128GB |
| NVRAM | 16GB |
| PCIe Expansion Slots (maximum) | 4 |
| FC Target Ports (32Gb autoranging, maximum) | 16 |
| 25GbE Ports | 16 |
| 100GbE ports (40GbE autoranging) | 4 |
| 10GbE BASE-T Ports (1GbE autoranging) (maximum) | 4 |
| Cluster Interconnect | 4x 25GbE |
| Storage Networking Supported | DM5100F: FC, iSCSI, NFS, pNFS, PMI, NVMe/FC, S3
DM5100F SAN*: FC, iSCSI, NVMe/FC * An optional software license upgrade is available for the DM5100F SAN and DM5000F SAN models to enable NAS support (NFS, pNFS, SMB file and S3 object storage connectivity). |
| Software Version | 9.8 or later |
| Shelves and Media | DM240N |
| Host/Client OSes Supported | Microsoft Windows, Linux, VMware ESXi |
| DM Series ALL-Flash Software | The DM Series software bundles include a set of products that delivers leading data management, storage efficiency, data protection, high performance, and advanced capabilities such as instant cloning, data replication, application-aware backup and recovery, and data retention. |
