| 기술 사양 |
| 매개변수 |
설명 |
| 모델 |
FusionServer 5885H V5 |
| 폼 팩터 |
4U 랙 서버 |
| Processors |
2 또는 4 1st Generation Intel® Xeon® Scalable processors (5100/6100/8100 시리즈), 까지 205 승 |
|
2 또는 4 2nd Generation Intel® Xeon® Scalable processors (5200/6200/8200 시리즈), 까지 205 승 |
| 메모리 |
48 DDR4 DIMM 슬롯, 2,933 MT/s; 까지 24 Intel® Optane™ PMem modules (100 시리즈), 2666 MT/s |
| Internal Storage |
Supports hot-swappable hard drives with the following configuration options: |
|
• 8 x 2.5-inch SA |
|
Supports hot-swappable hard drives with the following configuration options: |
|
• 8 x 2.5-inch SAS/SATA hard drives (앞쪽) |
|
• 24 x 2.5-inch SAS/SATA hard drives (앞쪽) |
|
• 25 x 2.5-inch SAS/SATA hard drives (앞쪽) |
|
• 16 x 2.5-inch SAS/SATA hard drives and 8 x 2.5-inch NVMe SSDs (앞쪽) |
|
• 24 x 2.5-inch NVMe SSDs (앞쪽) |
|
Flash storage: |
|
• Two M.2 SSDs |
|
S/SATA hard drives (앞쪽) |
|
• 24 x 2.5-inch SAS/SATA hard drives (앞쪽) |
|
• 25 x 2.5-inch SAS/SATA hard drives (앞쪽) |
|
• 16 x 2.5-inch SAS/SATA hard drives and 8 x 2.5-inch NVMe SSDs (앞쪽) |
|
• 24 x 2.5-inch NVMe SSDs (앞쪽) |
|
Flash storage: |
|
• Two M.2 SSDs |
| RAID |
RAID 0, 1, 5, 50, 6, 또는 60; optional supercapacitor to protect cache data from power failures; RAID 레벨 마이그레이션, 드라이브 로밍, 자가 진단, and web-based remote configuration |
| Network Ports |
2 엑스 10 GE + 2 x GE ports |
| PCIe 확장 |
• 최대 15 PCIe slots for 15 PCIe 3.0 슬롯 |
|
• 2 dual-width full-height full-length GPU cards (PCIe 3.0 x16) 또는 4 full-height half-length GPU cards (PCIe 3.0 x16) |
| Fan Modules |
5 hot-swappable fan modules with optional N+1 redundancy |
| 전원공급장치 |
4 hot-swappable PSUs with optional 2+2 중복성. Supported options include: |
|
• 1,500W AC Platinum PSUs |
|
• 900W AC PSUs |
|
• 1,200W DC PSUs |
| 관리 |
• BMC integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automated O&중, 및 하드웨어 보안 강화 |
|
• BMC supports standard interfaces such as Redfish, SNMP, 및 IPMI 2.0; HTML5/VNC KVM 기반 원격 관리 인터페이스 제공; supports CD-free deployment and the Agentless feature, simplifying management |
|
• (Optional) Configured with the FusionDirector management software to provide advanced management features such as stateless computing, batch OS deployment, and automated firmware upgrade, enabling smart and automatic entire-lifecycle management |
| 작동 온도 |
5ºC to 45ºC (41ºF to 113ºF) (ASHRAE A3 and A4 compliant) |
| Certifications |
CE, UL, FCC, CCC, 및 RoHS |
| 설치 제품군 |
L자형 가이드 레일, 조정 가능한 가이드 레일, 그리고 레일을 잡고 |
| 치수 (높이 x 너비 x 깊이) |
175 mm x 447 mm x 790 mm (6.89 ~에. 엑스 17.60 ~에. 엑스 31.10 안에.) |
