Technical Specifications |
Form Factor |
4U AI server |
Processor |
4th or 5th Gen Intel® Xeon® Scalable processors with 350 W TDP per processor |
Chipset |
Emmitsburg PCH |
Memory |
32 x DDR5 DIMMs, with up to 5600 MT/s speed |
Local Storage |
Hot-swappable drives in the following configurations: |
|
• Up to 28 x 3.5ʺ SAS/SATA drives |
|
• Up to 4 x NVMe SSDs |
|
Flash storage: |
|
• 2 x M.2 SSDs |
RAID |
RAID 0, 1, 10, 1E, 5, 50, 6, or 60; supercapacitors for cache data protection from power failures; RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration |
GPU Card |
4 x dual-width or 10 x single-width GPU cards |
Network |
Multiple network expansion capabilities |
|
2 x OCP 3.0 NICs, which can be configured as required and supports orderly hot swap and PCIe 5.0 |
PCIe Expansion |
Up to 10 x standard PCIe slots; supporting PCIe 5.0 |
Fan Module |
8 x hot-swappable counter-rotating fan modules in N+1 redundancy |
PSU |
4 x 1500 W Platinum, or 2000 W Platinum/Titanium hot-swappable PSUs with PSU1 and PSU2 in 1+1 redundancy and PSU3 and PSU4 in 1+1 redundancy |
Management |
The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening |
|
• The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management user interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management |
|
• Can be configured with the FusionDirector management software to provide advanced management features such as five intelligent technologies, enabling intelligent, automatic, visualized, and refined management through the lifecycle |
OS |
FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, and openEuler . For more, click here |
Security |
Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security bezel, secure boot, and chassis intrusion detection |
Operating Temperature |
5°C to 35°C (41°F to 95°F) (compliant with ASHRAE Class A1/A2) |
Certification |
CE, UL, CCC, FCC, VCCI, and RoHS |
Installation Suite |
L-shaped guide rails, adjustable guide rails, and holding rails |
Dimensions (H x W x D) |
175 mm x 447 mm x 798 mm (6.89 in. x 17.60 in. x 31.42 in.) |
