FusionServer 2488 V5 Rack Server

Technical Specifications
Parameter	Description
Model	FusionServer 2488 V5
Form Factor	2U rack server
Processors	2 or 4 1st Generation Intel® Xeon® Scalable processors (5100/6100/8100 series), up to 205 W
	2 or 4 2nd Generation Intel® Xeon® Scalable processors (5200/6200/8200 series), up to 205 W

Memory	32 DDR4 DIMM slots, 2933 MT/s; up to 8 Intel® Optane™ PMem modules (100 series), 2666 MT/s
Internal Storage	Supports hot-swappable hard drives with the following configuration options:
	8 x 2.5-inch SAS/SATA HDDs on the front
	25 x 2.5-inch SAS/SATA HDDs on the front
	8 x 2.5-inch NVMe SSDs and 16 x 2.5-inch SAS/SATA HDDs on the front
	Flash storage:
	2 x M.2 SSDs
RAID Support	RAID 0, 1, 10, 1E, 5, 50, 6, or 60 Configured with a supercapacitor for cache power-off protection Supports RAID level migration, drive roaming
LOM Network Ports	2 x GE + 2 x 10 GE ports
PCIe Expansion	Up to 9 PCIe 3.0 slots
Fan Modules	4 hot-swappable fan modules, providing protection against single-fan failures
Power Supply Units	2 hot-swappable PSUs, with support for 1+1 redundancy. The following PSUs are supported:
	2,000W AC Platinum PSUs
	1,500W AC Platinum PSUs
	900W AC Platinum PSUs
	1,200W DC PSUs
Management	BMC integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automated O&M, and hardware security hardening
	BMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management interface based on HTML5/VNC KVM; supports CD-free deployment and the Agentless feature, simplifying management
	(Optional) Configured with the FusionDirector management software to provide advanced management features such as stateless computing, batch OS deployment, and automated firmware upgrade, enabling smart and automatic entire-lifecycle management
Operating Temperature	5°C to 45°C (41°F to 113°F), compliant with ASHRAE Classes A3 and A4
Certifications	CE, UL, FCC, CCC, and RoHS
Installation Suite	L-shaped guide rails, adjustable guide rails, and holding rails
Dimensions (H x W x D)	86.1 mm (2U) x 447 mm x 748 mm (3.39 in. x 17.60 in. x 29.45 in.)
