| Technical Specifications |
| Parameter |
Description |
| Model |
FusionServer XH321 V6 |
| Form |
1U half-width 2-socket server node |
| Processor |
1/2 third-generation Intel® Xeon® Scalable processor (6300/8300 series) with 270 W TDP per processor |
| Memory Slots |
16 DDR4 DIMM slots, up to 3200 MT/s, up to 2 TB memory capacity (configured with 128 GB memory) |
| Local Storage |
A maximum of six 2.5-inch SAS/SATA/SSD/NVMe drives, and NVMe 2+4 balance |
|
Up to two M.2 2280 or 2242 SATA SSDs |
|
Hybrid configuration of different drive types |
| RAID |
RAID 0, 1, 5, 6, 10, 50, 60, and supercapacitor power failure protection |
|
RAID 0 and 1 for M.2 SSDs |
| PCIe |
2 standard PCIe 4.0×16 half-height half-length expansion slots |
| OCP |
1 OCP expansion slot |
| Management |
· The BMC chip integrates one dedicated management GE network port to provide comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening |
|
· The BMC supports standard interfaces such as Redfish, SNMP, and IPMI2.0. Provides a remote management interface based on HTML5/VNC KVM. CD-free deployment and agentless features simplify management. |
|
· Aggregates four compute nodes to any node management interface, simplifying management. |
|
· FusionDirector management software is optional. It provides advanced management features, such as stateless computing, batch OS deployment, and automatic firmware upgrade, implementing intelligent and automatic management throughout the lifecycle. |
| OS |
Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Citrix XenServer, and VMware ESXi |
| Security Features |
Such as power-on password, administrator password, TPM 2.0, security panel, secure boot, and cover opening detection |
| Operating Temperature |
5°C to 45°C (41°F to 113°F) |
| Certifications |
CE、UL、FCC、CCC、RoHS etc |
| Dimensions (H x W x D) |
40.7 mm x 218.7 mm x 632 mm (1.60 in. x 8.61 in. x 24.88 in.) |
