| Form Factor/Height |
1U rack server |
| Processor |
Up to 2x Intel® Xeon® 6 processors, up to 288 cores |
| Drive Bays |
- Up to 12x 2.5” or 16x EDSFF E3.S
- Front: Up to 10x 2.5” / 16x EDSFF E3.S (16x1T/8x2T), hot-swap
- Rear: 2x 2.5”, hot-swap
- 2x M.2 boot drives, optional hot-swap
- Direct NVMe, VROC/VMD (R0,1,5,10)
|
| Memory |
Supports up to 32x TruDDR5 RDIMMs, MCRDIMMs |
| Expansion Slots |
- Up to 5x PCIe 5.0 slots
- 2x OCP 3.0 slots
- 1x cabled internal HBA/RAID adapter
|
| GPUs |
Up to 3x single-width 75W GPUs |
| Network Interface |
2x OCP 3.0 (x8, cabled for x16) |
| Ports |
Front:
- Default LED and External diagnostic port
- Optional: USB-A (USB 10Gbps), one for XCC mobile & 1x mini-DP
- Optional: 2x PCIe 5.0 x16 slots & 1x OCP 3.0 x16 slot
Rear:
- 2x OCP 3.0 slots (x8/cabled x16)
- 1x VGA port
- 2 x USB 3.0 ports
- 1GbE dedicated management port
- Optional: 1x serial port
- Optional: 1x 2nd management port
|
| HBA/RAID Support |
- Intel VROC/VMD for NVMe RAID
- RAID controllers with 8 or 16 ports
- Non-RAID HBA with 8 or 16 ports
- Internal CFF 16i HBA/RAID
|
| Power |
- Dual Redundant AC & DC; Platinum & Titanium; 800W, 1300W, 2000W, and 1100W -48V DC Platinum
- Supports Industry standard CRPS form factor supplies
|
| Systems Management |
XClarity Controller v3 |
| OSes Supported |
- Microsoft
- SUSE
- Red Hat
- VMware
Visit lenovopress.com/osig for more information. |
| Limited Warranty |
- 1 and 3-year customer replaceable unit and onsite service
- Next business day 9am – 5pm
- Optional service upgrades
|
| Datasheet |
Lenovopress.com/ds0185 |
