| Form Factor/Height |
2U |
| Processor |
1x 4th or 5th Gen Intel® Xeon® Scalable processor, up to 350W TDP |
| Drive Bays |
- Front: 24x 3.5” HDD drives (support via 24 port SAS RAID/HBA card)
- Rear: 2x 2.5” NVMe SSDs
- Internal: 2x NVMe M.2 boot drives, VROC support
|
| Memory |
- 16x TruDDR5 RDIMMs, up to 1TB
- 1DPC @4800MHz; 2DPC@4400MHz
|
| Networking |
LOM via OCP & PCIe Adapters |
| Front I/O |
- Power Button with Power Status LED
- UID Button with UID LED
- Network Activity LED
- System Health LED, HDD warning LED
- 1x USB 3.2 Gen1 (5 Gbps)
|
| Rear I/O |
- Riser 1: x8 FHHL+ x16 FHHL PCIe Gen4
- Riser 2: x16 HHHL PCIe Gen4
- 1x OCP 3.0 PCIe Gen5 slot
|
| Power |
- 2x 1300W/1600W CRPS PT Power Supply Unit (PSU)
- 2x 1300W CRPS TT Power Supply Unit (PSU)
|
| Cooling |
Redundant Hot Swap Fans (N+1) |
| Management |
- Vertical DC-SCM 1.0
- 1x Management Network Port
- 2x USB 3.2 Gen1 (5 Gbps)
- VGA
- Power Button with Power Status LED
- System Health LED
- UID Button with UID LED
|
| Operating Systems |
Ubuntu 22.04.3 GA, RHEL 9.2, Rocky Linux 8.8, 9.2 |
| Limited Warranty |
Standard 3-year base warranty, extendable to 5 years |
| Datasheet |
Lenovopress.com/ds0173 |
