Ideal for High Performance

Dense-Computing environments

The Dell EMC PowerEdge R6525 Rack Server is a highly configurable, dual-socket 1U rack server that delivers outstanding balanced performance and innovations for dense compute environments

to address traditional and emerging workloads and applications.



Deliver breakthrough performance, innovation and density for traditional and emerging workloads

The new Dell EMC PowerEdge R6525 is a highly configurable, dual-socket 1U rack server that delivers outstanding balanced performance and innovation for dense compute environments. It’s ideal for traditional and emerging workloads and applications. High-level features include:

• 64 processing cores and faster data transfer speeds with PCIe Gen 4
• Up to 3200MT/s memory speed to reduce latency and deliver faster response
• Multi GPU support to accelerate end user VDI performance
• Highest core count PE 1U server with cryptographic isolation between hypervisor and VMs



Increase efficiency and accelerate operations with an automated infrastructure

The Dell EMC OpenManage™ systems management portfolio delivers an efficient and comprehensive solution for PowerEdge servers

through tailored, automated, and repeatable processes.

• Automate server life cycle management with scripting via the iDRAC Restful API with Redfish
• Simplify and centralize one to many management with the OpenManage Enterprise
• Utilize the OpenManage Mobile app and PowerEdge Quick Sync 2 to easily manage servers using a phone or
• Resolve issues with up to 72% less IT effort using automated proactive and predictive technology from ProSupport Plus and **



PowerEdge R6525 The PowerEdge R6525 provides a unique dense – 1U, dual-socket server – to address and scale traditional and emerging workloads like • High Performance Computing (HPC) • Virtual Desktop Infrastructure (VDI) • Virtualization

Fortify your data center with integrated security

Every PowerEdge server is designed with a cyber resilient architecture, integrating security deeply into every phase in the lifecycle, from design to retirement.

• Enhance security with platform enablement of AMD Secure Memory Encryption

(PME) and Secure Encrypted Virtualization (SEV).

• Operate your workloads on a secure platform anchored by cryptographically trusted booting and silicon root of
• Maintain server firmware safety with digitally signed firmware
• Detect and remediate unauthorized or malicious change with drift detection and system
• Securely and quickly wipe all data from storage media including hard drives, SSDs and system memory with System



**Based on June 2018 Principled Technologies Report commissioned by Dell EMC, “Save time and IT effort resolving server hardware issues with ProSupport Plus and SupportAssist”, compared to Basic Warranty without SupportAssist. Actual results will vary. Full report: http://facts.pt/olccpk



PowerEdge R6525
Features	Technical Specification
Processador	Two 2nd or 3rd Generation AMD EPYCTM Processors with up to 64 núcleos por processador
Memória	Até 32 x DDR4 Maximum RAM RDIMM 2 TB LRDIMM 4TB Max Bandwidth up to 3200 MT/S
Availability	Hot plug redundant Hard drives, fãs, PSUs
controladores	PERC 10.5 – HBA345, H345, H745, H840, 12G SAS HBA PERC 11 – H755, H755N Chipset SATA/SW RAID (S150): Sim
Compartimentos de movimentação	Front Bays Até 4 x 3.5” hot plug SAS/SATA (Disco rígido) Até 8 x 2.5” hot plug SAS/SATA (Disco rígido) Até 12 x 2.5” (10 Frente + 2 Traseira) hot plug SAS/SATA/NVMe	Optional Internal: 2 x M.2 (BOSS) Optional Rear: 2 x M.2 (BOSS-S2)
Power Supplies	800W Platinum 1400W Platinum 1100W Titanium
fãs	Hot plug Fans
Dimensões	Altura: 42.8milímetros (1.7”) Largura: 434.0milímetros (17.1”) Profundidade: 736.54milímetros (29”) Peso: 21.8kg (48.06lbs)
Rack Units	1U Rack Server
Embedded mgmt	iDRAC9 iDRAC RESTful API with Redfish iDRAC Direct Quick Sync 2 BLE/wireless module
Bezel	Optional LCD bezel or security bezel
OpenManage™ SW	OpenManage Enterprise OpenManage Enterprise Power Manager OpenManage Mobile
Integrations & Connections	OpenManage Integrations BMC Truesight Microsoft® System Center Redhat® Ansible® Modules VMware® vCenter™	OpenManage Connections IBM Tivoli® Netcool/OMNIbus IBM Tivoli® Network Manager IP Edition Micro Focus® Operations Manager I Nagios® Core Nagios® XI
Segurança	Cryptographically signed firmware Secure Boot Secure Erase	Silicon Root of Trust System Lockdown TPM 1.2/2.0, MTC 2.0 opcional
Embedded NIC	2 x 1 GbE LOM ports
Networking Options (NOC)	OCP x16 Mezz 3.0 + 2 x 1GE LOM
GPU Options	Até 2 Single-Wide GPU



PowerEdge R6525
Features	Technical Specification
Portas	Front Ports: 1 x Dedicated iDRAC direct micro-USB 1 x USB 2.0 1 x VGA	Rear Ports: 1 x Dedicated iDRAC network port 1 x Serial (opcional) 1 x USB 3.0 1 x VGA
PCIe	3 x Gen4 slots (x16) at 16GT/s
Operating Systems & Hypervisors	Canonical® Ubuntu® Server LTS Citrix® HypervisorTM Microsoft® Windows Server® with Hyper-V Red Hat® Enterprise Linux SUSE® Linux Enterprise Server VMware® ESXi®
OEM-ready version available	From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you. Para maiores informações, visit Dell.com/OEM.
Recommended support	Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region. Para maiores informações, visit Dell.com/ServiceDescriptions
